Tesa® 4952
Tesa 4952. Double-sided tape with PE foam backing and acrylic adhesive. This foam is highly conformable. This tape has been externally certified for mirror mounting.
Product benefits:
Versatile adhesive for immediate adhesion on many substrates.
Suitable for outdoors. UV, water and aging resistant.
Compensates for the difference in thermal expansion between two different materials.
High immediate adhesion even applying low pressure.
Excellent vibration absorption at low temperature.
– Very high resistance PE foam for constructive assembly.
– Permanent adhesion even in humid environments, smooth and uneven surfaces.
– LGA 329 1189 certificate (fixing mirrors).
– Damping effect.
Main applications
Mirror mounting.
Assembly of car mirrors.
Mounting of profiles.
Mounting of decorative panels.
Technical data Tesa 4952
| Support | PE foam | |
| Total thickness [µm] | 1150 | |
| Adhesion / steel [N / cm] | 6,5 (Foam break) | |
| Temperature resistance [° C] | ||
| Long term | 80 | |
| Short term | 80 | |
| PRODUCT | UNIT | PACKING | DIMENSIONS | COLOR |
| 4952 | Roll | 72 Rolls/Box | 19 mm x 1,5 mt (individual packaging-prof. presentation) |  |
| Roll | 60 Rolls/Box | 19 mm x 5 mt (individual packaging-prof. presentation) | | |
| Roll | 96 Rolls/Box | 19 mm x 10 mt (individual packaging-prof. presentation) | | |
| Roll | 32 Rolls/Box | 9 mm x 50 mt | | |
| Roll | 24 Rolls/Box | 12 mm x 50 mt | | |
| Roll | 20 Rolls/Box | 15 mm x 50 mt | | |
| Roll | 16 Rolls/Box | 19 mm x 50 mt | | |
| Roll | 12 Rolls/Box | 25 mm x 50 mt | | |
| Roll | 1 Roll/Box | 1360 mm x 50 mt | | |
| Roll | 1 Roll/Box | 1360 mm x 50 mt (Cutting) | | |
| Roll | 1 Roll/Box | 6 mm x 1800 mt | |
